针管韧性测试仪 /医用针管（针）韧性测试仪 （Needle Tube Toughness Tester/Medical Needle Tube (Needle) Toughness Tester）

践诺圭臬：

GB18457《制造医疗器械用不锈钢针管》、

GB15811《一次性使用无菌打针针》

概括：

医用针管（针）韧性测试仪有益用于东谈主体皮内、皮下、肌肉和静脉的打针针针管和其他医疗器械用硬直不锈钢针管的韧性测定，也称为打针针管针韧性测试仪、医用针管针韧性检察机等。该检测仪器自动化进度高，被测对象装上后，使用者仅按一下操作键即可自动完成一谈操作。

Excution Standards:

GB18457 "Stainless Steel Needle Tubes for Manufacturing Medical Devices"

GB15811 "Disposable Sterile Injection Needles"

summary:

The Medical Needle (needle) Toughness Tester is specifically used for the toughness determination of injection needles, needles, and other medical devices made of hard straight stainless steel needles for intradermal, subcutaneous, muscular, and venous injection in the human body. It is also known as an injection needle toughness tester, medical needle toughness testing machine, etc. The detection instrument has a high degree of automation, and after the tested object is installed, the user can automatically complete all operations with just one press of the operation key.

时间参数：

戒指系统：PLC;

操作界面：彩色7寸触摸屏，中英文切换

测试种类：打针针，消融针，输液针等

测试不同管径夹具：A1 0.2 ，A2 0.23-，A3 0.25 ，A4 0.3， A5 0.33 ，A6 0.36 ，A7 0.4 ，A8 0.45 ，A9 0.5 ，A10 0.55开云「中国」Kaiyun官网登录入口 ，A11 0.6， A12 0.7 ，A13 0.8 ，A14 0.9 ，A15 1.1 ，A16 1.2 A17 1.4， A18 1.6 ，A19 1.8， A20 2.1 ，A21 2.4 ，A22 2.7 ，A23 3.0 ，A24 3.4；

管壁：正常壁，薄壁，超薄壁三种任选；

公称规格：0.3-3.4mm；

检察频率：0.5Hz；

全自动逶迤角度：15°，20°，25°三种位置，开关设定逶迤角度，属于全自动测试；

全自动调遣逶迤距离：0-110mm，精度±0.1mm(10种规格)

实验次数：双向施力20次;

打印功能：镶嵌式袖珍打印机（热敏打印机）

净重：23KG;

外形尺寸：500*500*490mm

用电条目：220V-30A-50HZ

Technical Parameters:

Control system: PLC;

Operation interface: 7-inch color touch screen, switching between Chinese and English

Test types: injection needles, ablation needles, infusion needles, etc

Testing fixtures with different pipe diameters: A1 0.2, A2 0.23-，A3 0.25 ，A4 0.3， A5 0.33 ，A6 0.36 ，A7 0.4 ，A8 0.45 ，A9 0.5 ，A10 0.55 ，A11 0.6， A12 0.7 ，A13 0.8 ，A14 0.9 ，A15 1.1 ，A16 1.2 A17 1.4， A18 1.6 ，A19 1.8， A20 2.1 ，A21 2.4 ，A22 2.7 ，A23 3 ，A24 3.4；

Tube wall: Choose from three options: normal wall, thin wall, and ultra-thin wall;

Nominal specification: 0.3-3.4mm;

Test frequency: 0.5Hz;

Fully automatic bending angle: 15 °, 20 °, 25 ° three positions, switch setting bending angle, belonging to fully automatic testing;

Fully automatic adjustment of bending distance: 0-110mm, accuracy ± 0.1mm (10 specifications)

Experiment frequency: Apply force in both directions 20 times;

Printing function: Embedded micro printer (thermal printer)

Net weight: 23KG;

Dimensions: 500 * 500 * 490mm

Electricity requirements: 220V-30A-50HZ

旨趣：

为将针管的一端固定，从固定点到礼貌跨距的针管上施加一个力，最初向一个场地，然后向相悖场地逶迤一个礼貌的角度，如斯反复逶迤礼貌次数。

Principle:

To fix one end of the needle tube, apply a force from the fixed point to the needle tube with a specified span. First, bend it in one direction, then bend it in the opposite direction at a specified angle, and repeat this process a specified number of times.

行使畛域：

医疗器械制造：在医疗器械制造中，针管是基本的原材料之一，其韧性径直琢磨到医用家具的安全与有用性。针管韧性测试仪通过对针管进行力学性能测试，确保其在临床及实验室环境中的可靠性。举例，医用针管韧性测试仪不错测试多样不锈钢针管的力学性能，包括抗拉、抗压和抗弯等测试，确保针管在使用历程中的安全性和有用性。

制药：在制药行业中，针管是药物运输的要害通谈之一，其质地径直影响药物的安闲性和安全性。通过针管韧性测试仪的测试，制药企业不错评估不同针管材料的适用性，并接收稳妥的材料用于药物运输系统，确保药物的有用运输和患者的安全‌。

食物：天然针管韧性测试仪在食物畛域的行使不如在医疗器械和制药畛域闲居，但在某些特定情况下，如食物包装材料的检测中，也可能使用到近似的测试种植来确保包装材料的韧性和耐用性。

其他行使畛域：此外，针管韧性测试仪还在新材料研发、商场监管等方面有闲居行使。在新材料研发中，测试仪大概提供要害的性能数据撑捏，匡助研发东谈主员优化家具计算，提升家具的韧性和耐用性。

Application Areas:

Medical device manufacturing: Needles are one of the basic raw materials in medical device manufacturing, and their toughness directly affects the safety and effectiveness of medical products. The Needle Tube Toughness Tester ensures the reliability of the needle tube in clinical and laboratory environments by testing its mechanical properties. For example, the medical needle tube toughness tester can test the mechanical properties of various stainless steel needle tubes, including tensile, compressive, and bending tests, to ensure the safety and effectiveness of the needle tubes during use.

Pharmaceuticals: In the pharmaceutical industry, syringes are one of the key channels for drug delivery, and their quality directly affects the stability and safety of drugs. Through the Testing Of Needle Tube Toughness Tester, pharmaceutical companies can evaluate the applicability of different needle tube materials and select suitable materials for drug delivery systems, ensuring effective drug delivery and patient safety.

Food: Although the application of Needle Tube Toughness Testers in the food industry is not as widespread as in the medical device and pharmaceutical fields, similar testing equipment may also be used in certain specific situations, such as the testing of food packaging materials, to ensure the toughness and durability of packaging materials.

Other application areas: In addition, the Needle Tube Toughness Tester is widely used in new material research and development, market supervision, and other fields. In the development of new materials, testing instruments can provide critical performance data support, helping R&D personnel optimize product design, improve product toughness and durability.

援助器用：

夹具1套（0.2、0.23、0.25、0.3、0.33、0.36、0.4、0.45、0.5、0.55、0.6、0.7、0.8、0.9、1.1、1.2、1.4、1.6、1.8、2.1、2.4、2.7、3、3.4各1个）

Auxiliary Tools:

1 set of fixtures (1 each for 0.2, 0.23, 0.25, 0.3, 0.33, 0.36, 0.4, 0.45, 0.5, 0.55, 0.6, 0.7, 0.8, 0.9, 1.1, 1.2, 1.4, 1.6, 1.8, 2.1, 2.4, 2.7, 3, 3.4)
